金箔, As Rolled Temper, 0.0125mm厚
关注：2360
品牌：Goodfellow
产地：英国
纯度含量：99.95%
| 订货号 | 包装规格 |
| Coil | |
| 860-485-90 | 0.1 m |
| 811-326-78 | 0.2 m |
| 053-227-09 | 0.5 m |
| 408-305-99 | 1 m |
| 425-947-90 | 2 m |
产品参数
| Coil Width[卷材宽度] | 0.38mm |
| Purity[纯度] | 99.95% |
| Temper[状态] | As Rolled |
| Thickness[厚度] | 0.0125mm |
| Typical Analysis(典型分析) | |
| Ag | 80 PPM |
| Cu | 10 PPM |
| Fe | 3 PPM |
| Mg | 1 PPM |
| Si | 1 PPM |
| Mechanical Properties(机械性能) | |
| Bulk modulus ( GPa ) ( Hard ) | 171.0 |
| Bulk modulus ( GPa ) ( Soft ) | 171.0 |
| Hardness - Vickers ( kgf mm⁻2 ) ( Hard ) | 60 |
| Hardness - Vickers ( kgf mm⁻2 ) ( Soft ) | 20 - 30 |
| Material condition | Soft |
| Material condition | Hard |
| Poisson's ratio ( Hard ) | 0.420 |
| Poisson's ratio ( Soft ) | 0.420 |
| Tensile modulus ( GPa ) ( Hard ) | 78.50 |
| Tensile modulus ( GPa ) ( Soft ) | 78.50 |
| Tensile strength ( MPa ) ( Hard ) | 220.00 |
| Tensile strength ( MPa ) ( Soft ) | 130.00 |
| Yield strength ( MPa ) ( Hard ) | 205.0 |
| Atomic Properties(原子属性) | |
| Atomic number | 79 |
| Atomic weight ( amu ) | 196.96650 |
| Crystal structure | Face Centred Cubic |
| Electronic structure | Xe4f1⁴5d1⁰6s1 |
| Ionisation potential ( No./eV ) | 1 / 9.22 |
| Ionisation potential ( No./eV ) | 2 / 20.5 |
| Photo-electric work function ( eV ) | 4.80 |
| Thermal neutron absorption cross-section ( Barns ) | 98.8000 |
| Valences shown | 1 ,3 |
| Thermal Properties(热性能) | |
| Coefficient of thermal expansion ( x10⁻⁶ K⁻1 ) | 14.100 @0-100℃ |
| Latent heat of evaporation ( J g⁻1 ) | 1738 |
| Latent heat of fusion ( J g⁻1 ) | 64.90 |
| Melting point ( C ) | 1064.40 |
| Specific heat ( J K⁻1 kg⁻1 ) | 129.0 @25℃ |
| Thermal conductivity ( W m⁻1 K⁻1 ) | 318.00 @0-100℃ |
| Electrical Properties(电气特性) | |
| Electrical resistivity ( μOhmcm ) | 2.2@20℃ |
| Temperature coefficient ( K⁻1 ) | 0.00400 @0-100℃ |
| Thermal emf against Pt (cold 0C - hot 100C) ( mV ) | 0.74 |
| Physical Properties(物理性质) | |
| Boiling point ( C ) | 3080 |
| Density ( g cm⁻3 ) | 19.300 @20℃ |
其他参数
公差
| 长度 | <100mm | ±1mm |
|---|---|---|
| ≥100mm | +2% / -1% | |
| 直径 | <100mm | ±1mm |
| ≥100mm | +2% / -1% | |
| 厚度 | <0.01mm | ±25% |
| ≤0.05mm | ±15% | |
| >0.05mm | ±10% | |
| 长度 1 | <100mm | ±1mm |
| ≥100mm | +2% / -1% | |
| 长度 2 | <100mm | ±1mm |
| ≥100mm | +2% / -1% |
产品发布日期：2026.01.24
Goodfellow（顾特服）
